For a spectacular image made possible by HDR10 and Dolby Vision, plus the enveloping, multi-dimensional audio of DTS:X™ and Dolby Atmos®, upgrade to the PE-VSX-LX302.
For a spectacular image made possible by HDR10 and Dolby Vision, plus the enveloping, multi-dimensional audio of DTS:X™ and Dolby Atmos®, upgrade to the PE-VSX-LX302. This receiver features built-in Chromecast, FireConnect™, and DTS Play-Fi® so it can stream music across multiple systems. Additional highlights include on-the-go control through the Pioneer Remote App, a phono input for vinylheads who want a turntable option, as well as a variety of other integrated internet radio and network streaming services. It even includes Powered Zone 2 and 6 HDMI inputs for a wide range of multi-room options.
When used with 4K-optimized displays, this receiver passes Ultra HD 4K@60Hz 4:4:4 at the highest quality, so you can send premium 4K video content with digital copy protection in the blink of an eye.
Now, your customers can enjoy images that are sharper and brighter than ever, since this receiver supports HDR10 and Dolby Vision. All you need to do is hook up the source device so they can view the latest video standards on a compatible display. Even better, this receiver’s HDMI terminals support 4K, BT.2020, and HDCP 2.2, so future-proofing installs just got easier.
Compatible with 5.1.2ch and 5.2.2ch configuration of the latest theater sound platform, this receiver’s Dolby Atmos® configuration lets customers experience the subtlest sounds in multi-dimensional space. It can reproduce object-oriented sound in smooth, curving movements, or in a realistic three-dimensional movement overhead by the top speakers.
Enabling newly immersive and interactive audio experiences for your customers, DTS:X leverages object-based audio to take sound systems to the next level. Since DTS:X can automatically adapt sounds into any existing channels or speaker systems, no specific speaker layout is required to make the most of an install. Each soundscape will now deliver incredibly rich, lifelike audio that feels custom-designed.
Developed with the expertise of professional recording studios, Multi-Channel Acoustic Calibration System (MCAAC) automatically compensates for differences in speaker size, level and distance, and equalizes response. Whether your customer is watching the latest Hollywood blockbuster or enjoying high-resolution music, MCACC will make sure their home theater sounds its very best.
Enjoy network features such as audio streaming via a strong wireless LAN connection. Built-in dual-band Wi-Fi supports both 5 GHz and 2.4 GHz frequency channels, so customers can enjoy steady and uninterrupted streaming of audio files without buffering or annoying lag times.
This receiver offers a limitless flow of streaming music, sports, talk, and news entertainment from internet radio stations and online music services, including Pandora, Spotify, TuneIn, TIDAL, and Deezer. Please note: Pandora service is only available in the U.S.
Customers can use mobile devices to stream their favorite music, radio, or podcasts to a speaker through built-in Chromecast. Through app-compatible iOS and Android devices, plus Mac, Chromebook, and Windows PCs, Chromecast lets end users control audio from anywhere in the house. Many popular Chromecast-enabled apps are available at g.co/cast/audioapps.
For those vinyl-obsessed customers who want to put their records on, Pioneer includes an MM Phono input on all Pioneer Elite receivers. Now, your customer can enjoy their classic collections all over again.
PE-VSX-LX302 |
---|
3U |
7.2-Channel |
100W |
Class AB |
Dolby Atmos® for 3.1.2ch/Dolby Surround, DTS:X/DTS Neural:X Dolby® TrueHD/Dolby Digital Plus DTS-HD Master Audio/DTS-HD High Resolution Audio/DTS 96/24/DTS-ES DTS-HD Express |
Surround Enhancer Reflect Optimizer |
DSD Disc (SACD) Playback via HDMI (2.8 MHz/5.1ch, 2ch) Digital Core Engine with Cirrus Logic (Quad Core) x1 384 kHz/32-bit DAC (AK4438) HDMI Audio Return Channel (ARC) |
MCACC Auto Room Tuning Phase Control Subwoofer EQ |
Advanced Sound Retriever (2ch) Advanced Surround Modes |
Zone 2 (powered and pre-out) |
HDR10 and BT.2020 Support Dolby Vision Compatible Ultra HD Upscaling (1080p - 4K) Video Transcoder (analog composite & analog component to HDMI) |
RCA Analog Audio x 5 RCA Analog Video x 2 3.5mm Analog Line In Component Analog Video In x 1 Toslink x 2 In Coax x 1 In USB x 2 In Subwoofer x 2 Out |
7 In / 2 Out |
Yes 4K/60p/4:4:4 |
Yes |
36-bit |
2.2 |
x 1 |
None |
Out x 1 |
None |
Yes |
FireConnect (future firmware update) Chromecast built-in DTS Play-Fi ready (future firmware update) Apple AirPlay certified Pandore Spotify TIDAL Deezer Internet Radio w/ TuneIn |
Remote Control, Setup Microphone, AC Power Cord |
480W / Standby: 0.15W |
17.1" x 6.8" x 14.6" |
22 lb |
Rack Spacing |
Channels |
Power Output @ 8 ohm |
Topology |
Supported Formats |
Audio Features |
Decoders |
Soundfield Calibration |
Listening Modes |
Zones |
Video Processing |
Connectors |
HDMI Connections |
HDMI 4K Support |
HDMI Deep Color Support |
HDMI Max Color Depth |
HDCP Compliance |
IR Inputs |
IR Outputs |
12V Trigger |
HDBaseT Connections |
RS-232 Ports |
Streaming |
Included Accessories |
Power Consumption |
Dimensions (W x H x D) |
Weight |
