The Atlona AT-HDVS-200-RX is an HDBaseT receiver and HD scaler for video signals up to 1080p, plus embedded audio, control, and Ethernet over distances up to 330 feet (100 meters).
The Atlona AT-HDVS-200-RX is an HDBaseT receiver and HD scaler for video signals up to 1080p, plus embedded audio, control, and Ethernet over distances up to 330 feet (100 meters). It’s designed for use with the HDVS-200-TX switching transmitters, but can also be used with Atlona switchers, matrix switchers, and distribution amplifiers with HDBaseT outputs. Together, the HDVS-200-TX and HDVS-200-RX serve as a compact, fully automated AV system with the convenience of automatic input selection, display control, and HD scaling. The HDVS-200-RX remotely powers the HDVS-200-TX through Power over Ethernet (PoE).
The HDVS-200-RX offers advanced scaling capabilities including image adjustment capability, and a feature for automatically matching incoming signals to the display’s native resolution. Integrated scaling and video processing help optimize image quality and switching performance. This receiver also features audio de-embedding, and third-party TCP/IP and RS-232 control of the scaler and display. Additionally, the HDVS-200-RX includes contact closure ports for controlling a motorized screen or display lift.
The HDVS-200-RX combines the benefits of HD scaling and integrated display control, and the advantages of HDBaseT signal extension. It incorporates many popular integration convenience features while delivering excellent value for classrooms, huddle rooms, and meeting spaces. Surface mounting brackets are provided with the HDVS-200-RX for easy installation behind a display or above a projector.
Providing two channel, analog audio signal on balanced captive screw connectors, this receiver improves AV system audio with the use of an external amplifier, such as the Atlona AT-PA100-G2.
Using a CAT6a/7 cable, this device receives 4K UHD up to 330 feet (100 meters). Use it with a CAT5/6 to receive AV, control, and Ethernet signals @ 1080p up to that same distance. Atlona provides low-cost, reliable system installation using these easy-to-integrate category cables.
This receiver scales video signals up to 1080p @60Hz and at a 1920×1200 resolution. For a PC source, you can easily set desired input resolution from 800×600 to 1920×1200. Incoming signals can also be automatically scaled to the display’s native resolution.
When used in conjunction with an HDVS-200-TX transmitter (or compatible Atlona switcher), the HDVS-200-RX can provide control to a display through TCP/IP, RS-232, or CEC*, without the need for a separate control system. This simplifies system design and integration while reducing costs. With automatic display control, the HDVS-200-RX can trigger a display to power on automatically whenever a laptop or other device is connected to the HDVS-200-TX. At the end of the presentation, when the presenter disconnects the laptop, the HDVS-200-RX forces the display to power off. Ease of presenter interaction with the system, and the savings incurred by automatic display shutdown provide a significant return on investment. The HDVS-200-RX display control capability can also be triggered by an external control system. Front panel volume controls are also available to control the display’s internal audio, or another device with volume control, such as a DSP or another switcher.
Integrators can now set or match a PC’s graphics resolution by using this receiver between a source device and a display. Please note that when using this receiver with an AT-HDVS-200-TX, EDID management is required from the transmitter instead of the receiver.
This receiver provides POE power when paired with the AT-HDVS-200-TX switcher, saving you time and integration costs by supplying power to the transmitter over HDBaseT. No local AC outlet is required for the AT-HDVS-200-TX. It operates at the industry standard IEEE 802.3af PoE.
We offer a wide range of communication equipment—including switchers, receivers, transmitters, converters, and more—that work together to create fully-integrated commercial conferencing solutions.
| AT-HDVS-200-RX |
|---|
1.4 |
CAT5e/6 @ 1080p: up to 330 feet HDMI IN/OUT @ 1080p: up to 30 feet |
Unit: CE, FCC |
5" x 1.5" x 4.02" |
20 to 90% non-condensing |
32°F to 122°F |
-4°F to 140°F |
6.75 Gbps |
HDCP Compliance |
Transmission Distance |
Certifications |
Dimensions (W x H x D) |
Operating Humidity |
Operating Temperature |
Storage Temperature |
Bandwidth |
We want to make our Third-Party Partner program as easy as possible. That’s why we process all claims directly, without any third party telephone tag. Specific warranty terms and details from the manufacturer are below. View the full Atlona® Warranty.
