The Atlona AT-OME-PS62 is a 6×2 matrix presentation switcher with HDMI, USB-C, and HDBaseT inputs, plus HDMI and HDBaseT outputs. Part of the Omega™ Series of integration products for modern AV communications and collaboration, the OME-PS62 features HDBaseT extension for video up to 4K/60 4:2:0, plus embedded audio, control, Ethernet, and USB over distances up to 330 feet (100 meters).
The Atlona AT-OME-PS62 is a 6×2 matrix presentation switcher with HDMI, USB-C, and HDBaseT inputs, plus HDMI and HDBaseT outputs. Part of the Omega™ Series of integration products for modern AV communications and collaboration, the OME-PS62 features HDBaseT extension for video up to 4K/60 4:2:0, plus embedded audio, control, Ethernet, and USB over distances up to 330 feet (100 meters). The HDMI and USB-C inputs support video up to UHD/60 4:4:4. The OME-PS62 is HDCP 2.2 compliant and features 4K/60 4:4:4 upscaling and downscaling for the HDMI output. Integrated USB extension addresses the challenge of connecting between USB devices at remote locations, and is ideal for software video conferencing and touch or interactive displays. The OME-PS62 includes USB 3.0 and USB-C interfaces for three host PCs, plus two peripheral devices such as a camera, microphone, speakerphone, or keyboard and mouse. This versatile matrix presentation switcher is ideal for a wide range of 4K presentation applications with Omega Series transmitters and receivers.
| AT-OME-PS62 |
|---|
1x Line/Mic In, 6 pin captive screw, balanced / unbalanced line level input w/3-pin MIC option 1x Line Mic Switch: - 3 position switch - Mix, 48V, and Line 2x Audio In 5-pin captive screw, balanced / unbalanced 2-channel 2x Audio Out 5-pin cap |
In: 2x RJ45, female Out: 1x RJ45, female |
In: 3x Type A, 19-pin female Out: 1x Type A, 19-pin female |
Device control and configuration
Bidirectional pass-through from control system over HDBaseT
Supported baud rates: 2400, 4800, 9600, 19200, 38400, 57600, 115200 |
HDMI In/Out: @4k/UHD 15 ft (5m) @1080p 30 ft (10m) CAT5e: @4k/UHD 295 ft (90m) @1080p 330 ft (100m) CAT6/6a/7: @4k/UHD 330 ft (100m) @1080p 330ft (100m) |
Device: CE, FCC, UL |
17.24 in. x 1.73 in. x 10 in. |
Control Buttons:Menu, Nav, and Number : 10x, tact type IP Mode, Reset: 2x recessed |
2x - 3-pin captive screw (bidirectional) |
-4-140°F (-20-60°C) |
USB Hub: 2x Type A, 4-pin female USB Host: 2 Type A, 4-pin female |
7.76 lbs |
2560×1600, 2048×1536, 1920×1200, 1680×1050, 1600×1200, 1440×900, 1400×1050, 1280×1024, 1280×800, 1366×768, 1360×768, 1152×864, 1024×768, 800×600, 640×480 |
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz |
Yes |
100 – 240 VAC, 50/60 Hz |
2x green IP Mode, Reset |
2x RJ45, 100Base-T |
HDR10, Hybrid-Log Gamma (HLG), and Dolby® Vision™ @ 60Hz; HDMI and USB-C ports only |
Protocols: HTTPS, Telnet, mDNS Modes: DHCP, Static – selectable through front panel and webGUI |
HDMI / HDBaseT Pass-Through Formats: PCM 2.0, LPCM 5.1, LPCM 7.1, Dolby® Digital, Dolby Digital Plus™, Dolby TrueHD, Dolby Atmos®,
DTS® Digital Surround™, DTS-HD Master Audio™, and DTS:X® |
24 bits |
Compliance: 2.0 Max Data Rate: 120 Mbps USB-C: Supports Audio, Video, and device & host data. Up to 4K/UHD @ 60Hz |
4096x2160@60(1)/50/30/25/24Hz, 3840×2160@60(1)/50/30/25/24Hz, 1080p@60/59.9/50/30/29.97/25/2
4/23.98Hz, 1080i@30/29.97/25Hz, 720p@60/59.94/50Hz, 576p@50Hz, 576i@25Hz, 480p@60/59.96Hz,
480i@30Hz |
YUV, RGB |
4:4:4, 4:2:2, 4:2:0 |
8-bit, 10-bit, 12-bit |
HDMI 2.0(1.4 when downscaled), HDCP 2.2/1.4 |
32-122°F (0-50°C) |
20-60% non-condensing |
Unit only: 58W Full load: 170W (while powering USB-C device up to 60W, HDBaseT PoE devices up 15W each, and USB type A devices up to 2.5W each) |
Connector Type |
HDBaseT Connections |
HDMI Connections |
RS232 Control |
Transmission Distance |
Certifications |
Dimensions (W x H x D) |
Features |
RS-232 Ports |
Storage Temperature |
USB Ports |
Weight |
VESA Resolution |
Supported Sample Rates |
CEC |
External Power Supply |
LED Indicators |
LAN Connection |
Video Features |
IP Control |
Audio Pass Through |
Audio Bit Depth |
USB Description |
Video Resolution |
Colorspace |
Chroma Subsampling |
Color Depth |
HDMI Compliance |
Operating Temperature |
Operating Humidity |
Power Consumption |
